Nikon N80/F80 Specifications |
||||||||||
| Picture
| Home Infrared film cannot be used with this camera, because the F80 detects the film perforation with an infrared ray. |
||||||||||
| Type of camera | Integral-motor autofocus 35mm single-lens reflex with electronically controlled focal-plane shutter | |||||||||
| Exposure modes | Programmed Auto (Flexible Program possible™); Shutter-Priority Auto; Aperture-Priority Auto; Manual | |||||||||
| Picture Format | 24mm x 36mm (standard 35mm film format) | |||||||||
| Lens mount | Nikon F mount (with AF coupling, AF contacts) | |||||||||
| Compatible lenses | Nikkor and
Nikon lenses with Nikon F mount with limitations :
|
|||||||||
| Diopter Adjustment | -1.8 to +0.8 DP | |||||||||
| Viewfinder Eyepoint | 15.5 to 20mm | |||||||||
| Focusing screen | Nikon Advanced Focusing Screen with Vari-Brite focus area and On-Demand Grid Lines | |||||||||
| Finder magnification | Approx. 92% Approx. 0.75x with 50mm lens set to infinity and -1.0 DP | |||||||||
| Viewfinder information | Focus indications, metering system, AE lock, shutter speed, aperture, exposure mode, electronic analogue display/exposure compensation display, frame counter/exposure compensation, ready-light, multiple exposure, focus area, flash exposure compensation, focus area brackets, 12mm circle for Center-Weighted metering, On-Demand Grid Lines | |||||||||
| Reflex mirror | Automatic, instant-return type | |||||||||
| Lens aperture | Instant-return type, with depth-of-field preview button | |||||||||
| Autofocus | TTL phase detection, Nikon Multi-CAM900 autofocus module - Detection range: EV -1 to EV 19 (ISO 100, at normal temperature). | |||||||||
| Lens Servo | Single Servo AF (S), Continuous Servo AF (C), Manual focus (M) - Focus Tracking automatically status activated | |||||||||
| Focus area | One of five focus areas can be selected | |||||||||
| AF Area mode | Single Area AF and Dynamic AF (Dynamic AF Mode with Closest Subject Priority also available) | |||||||||
| Focus lock | Focus is locked by pressing AF-L/AE-L button or lightly pressing shutter release button in Single Servo AF | |||||||||
| Metering system | 10 segment 3D Matrix Metering, 75/25 Center-Weighted Metering & Spot Metering | |||||||||
| Metering range | 3D Matrix Metering: EV 0-21; Center-Weighted Metering: EV 0-21; Spot Metering: EV 3-21 (at norm temp., ISO 100, 50mm f/1.4) | |||||||||
| Exposure meter coupling | CPU and AI combined | |||||||||
| Exposure compensation | Exposure compensated in ±3 EV range, in 1/2 steps | |||||||||
| Auto Exposure Lock | Detected exposure value locked by pressing AF-L/AE-L button | |||||||||
| Auto Exposure: | Two or three frames, 1/2 steps | |||||||||
| Film speed setting | DX or manual selectable: Film speed range: DX: ISO 25-5000, Manual: ISO 6-6400 in 1/3 steps | |||||||||
| Shutter | Electronically controlled vertical-travel focal-plane shutter | |||||||||
| Shutter speeds | 30 seconds to 1/4000 of second. plus Bulb | |||||||||
| Additional controls | 18 user programmable Custom Settings | |||||||||
| Sync contact | X-contact only; flash synchronization up to 1/125 sec. | |||||||||
| Built-in TTL Speedlight | Guide number: 39 (ISO 100, ft) flash coverage: 28mm or longer lens; Red-Eye Reduction, TTL flash control including 3D Multi-Sensor Balanced Fill-Flash, Slow Sync and Rear-Curtain Sync are possible | |||||||||
| Flash control | 5-segment TTL Multi Sensor w/ 3D Multi-Sensor Balanced Fill-Flash with built-in Speedlight, SB-28DX, SB-28, SB-27, SB-26, SB-25 | |||||||||
| Monitor Pre-flash | Built-in TTL Speedlight or Nikon Speedlight SB-28DX/28/SB-27 fires Monitor Pre-flash(es) when AF Nikkor or AI-P Nikkor lens is used | |||||||||
| Flash sync mode | Front-Curtain Sync (normal sync), Red-Eye Reduction, Red-Eye Reduction with Slow Sync, Slow Sync, Rear-Curtain Sync | |||||||||
| Ready-light | Lights up when flash fully charged with built-in Speedlight and SB-28DX, 28, etc.; blinks (3 sec. after flash) for full output warning | |||||||||
| Accessory shoe | Standard ISO-type hot-shoe | |||||||||
| Self-timer | Electronically controlled; timer duration: 2 to 20 seconds with Custom Setting. | |||||||||
| DOF preview button | Stops down lens aperture when pressed | |||||||||
| Film loading | Film automatically advances to first frame when shutter release button is pressed once (shutter and mirror not activated) | |||||||||
| Film advance | Automatic advance with built-in motor; S (Single) or C (Continuous) modes available | |||||||||
| Film advance speed | S: One frame advance - C: Continuous shooting; Approx. 2.5 fps (AA-type alkaline batteries) | |||||||||
| Film rewind | Auto rewind with built-in motor. Rewind speed with 36-exp. film: approx. 15 sec. Quiet rewind mode speed approx. 23 sec. | |||||||||
| Multiple exposure | Activated using film advance mode dial | |||||||||
| LCD panel information (with built-in illuminator) | DX indication, shutter speed/exposure compensation value, aperture, exposure compensation, Auto Exposure/Flash Exposure Bracketing, Bracketing bar graphs, Custom, Flexible Program, flash sync mode, AF area mode, focus area, battery power, frame counter | |||||||||
| Power source | Two CR123A batteries | |||||||||
| Exposure meter | Auto meter shut-off approx. 6 sec. | |||||||||
| Usable number of film rolls (approximate) | With 36-exposure
film, for Continuous Servo autofocus operation using an
AF Zoom-Nikkor 28-80mmf/4-5.6D lens, in single-frame
shooting, covering the full range from infinity to the
closest distance and back to infinity before each shot,
without intervals between shots, with a shutter speed of
1/125th sec. or faster.
|
|||||||||
| Two-Button Reset | Pressing the BKT and Exp. Compensation buttons simultaneously and holding them for more than 2 sec. resets most settings to their original default settings | |||||||||
| Dimensions (W x H x D) | Approx. 141.5 x 98.5 x 71 mm ( 5.6 x 3.9 x 2.8 in.) | |||||||||
| Weight (without batteries) | Approx. 515g (18.2 oz) | |||||||||
All specifications apply when fresh CR-123A batteries are used at normal temperature (20°C - 68°F). |
||||||||||
Notes:
F80 has 3 versions : the standard F80, the QD version (F80D) and a special QD model (QD F80S) that imprints data ( shutter speed, aperture and exposure compensation values) between frames (in any exposure mode). Each is offered in black; the F80 and F80D are also available in silver-coloured models.
The new Focusing Screen Display system for the F80 incorporates a Polymer Network LCD .
The viewfinder image will become slightly darker when batteries are not installed.
